PLC Control desktop 4 filling nozzles fluid peristaltic pump filling machine

  • Application
  • Description
  • Products Parameters
  • Video
  • Package&Shipping
  • FAQ
Application

It is suitable for various corrosive, low viscosity and non-particulate liquids, such as: various chemicals (medicine oil, medicinal liquor, alcohol, eye drops, syrup), chemicals (solvent, acetone), oil (edible oil, essential oil), cosmetics (toner, makeup remover, spray), food (100 degree high temperature, such as milk, soy milk), beverage (juice, fruit wine), seasoning (soy sauce vinegar) and other non-particulate liquid; high and low foam liquid ( Care solution, detergent).

PLC Control desktop 4 filling nozzles fluid peristaltic pump filling machine

Product Description
PLC controll desktop full automatic machine is very efficient with high cost performance. It is widely used in medicine, daily chemical and other industries such as essential oils, perfumes, juice liquid etc. Machine with magnetic pump is good choice for low viscous corrosive, a little foamy liquid. 316 stainless steel pump can use for very high temperature liquid fill.

PLC Control desktop 4 filling nozzles fluid peristaltic pump filling machine

Specification
Machine Model
TLFM-M4
Power Supply
110/220V 50-60HZ
Maximum Flow Velocity
5500ml/min
(Each nozzle and base on water)
Working Speed
20-30 bottles/min
(based on 50-1500ml filing volume)
Air Pressure
0.3-0.4MPa
Filling Accuracy
≤±1% (For water)
Diameter of Flling Nozzle
≤±1% (For water)
Delay Range
0.01-999.9s
Count Range
1-99999 Times
Filling Volume
5- 1500ml
Size of Air Compressor Connector
OD8mm
Bottle Height
<220mm(Can be customized,max height 300mm)
Package Size
About 1290*860*720mm
Gross Weight
About 70 kg

PLC Control desktop 4 filling nozzles fluid peristaltic pump filling machine

PLC Control desktop 4 filling nozzles fluid peristaltic pump filling machine

PLC Control desktop 4 filling nozzles fluid peristaltic pump filling machine

FAQ
Q1: Are you a machine manufacturer or trading company?A1: We are a reliable machine manufacturer that could gives u best service. And our machine can be customized by client's requirement. Welcome to visit our factory!
Q2: How do you guarantee this machine normally operating?A2: Every machine is tested by our factory and other client before shipping, We will adjust the machine to optimal effect before delivery. And spare is always available and free for you in warranty year.
Q3: How can I install this machine when it arrives?A3: We will send the engineers overseas to help client installing, commissioning and training.
Q4: Could I choose the language on touch screen?A4: It's no problem. You can choose Spanish, French, Italian, Arabic, Korean, etc,.
Q5: What should I do to choose the best machine for us?A5: 1) Tell me the material you want to fill, we'll choose the suitable type of machine for you to consider. 2) After choose the suitable type of machine, then tell me the filling capacity you need for the machine. 3) At last tell me the inner diameter of your container to help us choose the best diameter of the filling head for you.
Q6: Do you have manual or operation video for us to know more about the machine?A6: Yes, we will send you the manual and operation video after you ask for us.
Q7: If there's some spare parts that broke, how to solve the problem?A7: Yes, we will send you the manual and operation video after you ask for us.
Q8: If there's some spare parts that broke, how to solve the problem?A8: First of all, please take the pic or make a video to show the problem parts. After the problem is confirm from our sides, we'll send you the spare parts for free, but the shipping cost should be paid by your side.
Q9: Do you have manual or operation video for us to know more about the machine?A9: Yes, we will send you the manual and operation video after you ask for us.
Q10: If there's some spare parts that broke, how to solve the problem?A10: Yes, we will send you the manual and operation video after you ask for us.
Q11: If there's some spare parts that broke, how to solve the problem?
A11: First of all, please take the pic or make a video to show the problem parts. After the problem is confirm from our sides, we'll send you the spare parts for free, but the shipping cost should be paid by your side.
