Introduction To The Working Principle Of Perfume Filling Machine

Find here details of Liquid Filling Machine. If you need any information, welcome to follow our website.

Perfume Filling Machine is suitable for pharmaceutical, chemical, food, light industry and other industries to use vacuum negative pressure and self-priming equipment for glass, plastic, metal and other containers. The machine should be used for the diameter of the container to be filled, within the caliber. The liquid surface uplift stress should be greater than the liquid static pressure, which means that the liquid will not flow out after the container is inverted. Such as oral liquid plastic bottles. Wind oil bottle, eye drops bottle, cosmetic perfume bottle, battery liquid filling, etc.

Perfume Filling Machine

The vacuum filling machine (self-discharging type) works by opening the hand valve and connecting it to the air source. Place the bottle to be filled directly under the filling head, and use the elasticity of the bottle shelf to make the bottle straight and seal with the filling head. At this point, the cam opens the mechanical valve and closes the vacuum bottle valve and opens the suction valve, causing the vacuum generator to generate a vacuum (negative pressure).

Form a vacuum environment system (vacuum bottle - filling head - filling bottle - filling head silicone tube). The vacuum suction allows the material to be poured into the bottle. When the bottle material rises to the height of the outer casing of the filling head. As the vacuum suction passes through the outer casing, the contents of the bottle are sucked into the vacuum bottle so that the contents of the bottle are always kept at a certain height until the filling bottle is removed. The mechanical valve is closed and the vacuum generator stops generating a vacuum. The suction tube is closed. The vacuum bottle valve is opened, and the vacuum bottle internal material flows into the material tank due to gravity to complete a filling cycle.

Based on the reference to foreign similar products, it has been redesigned and added some additional functions. It makes the product more convenient and convenient in terms of operation, precision error, capacity adjustment, equipment cleaning and maintenance.

The all-pneumatic filling machine designed on this basis uses pneumatic components instead of electrical control loops, making it particularly suitable for use in environments with explosion-proof requirements.
